SD-S630 Saddle fusion machine
联系电话：13915274520
Application and features：
※ Suitable for fabricating PE reducing tee in a workshop.Integrated function of wdlding and taping enables to complete the whole fabricating process.
※ Removable PTFE coated heating plate.
※ Separate two-channel timer records times in soaking and cooling phases.
※ Digital high-accurate pressure meter indicates clearer readings.
※ Linear guide ways are equipped with heating plate and dragging plate.
The main parameters：
Model | SD-S630 |
Working ranges | Reducing tee |
Main pipe max.Dia | 630mm |
Branch pipe max.Dia | 315mm |
Heating plant max.Temp | 270℃ |
System pressure ranges: | 0-16MPa |
Working voltage: | 380V±10%，50Hz |
Heating plate power: | 8 |
Hydraulic unit power: | 1.5Kw |
Drill motor power: | 1.5 |
Total power | 11Kw |
EN ISO 1200-1,EN 1200-2,EN 1050,60204-1
Model | SD-S630 | ||||||
Main pipe Branch pipe | 315 | 355 | 400 | 450 | 500 | 560 | 630 |
110 | ▲ | ▲ | ▲ | ▲ | |||
160 | ▲ | ▲ | ▲ | ▲ | ▲ | ▲ | |
200 | ▲ | ▲ | ▲ | ▲ | ▲ | ||
225 | ▲ | ▲ | ▲ | ▲ | |||
250 | ▲ | ▲ | ▲ | ||||
315 | ▲ | ||||||
